Nexperia USA Inc. HEF4051BTS,112

Part No.:: HEF4051BTS,112

Manufacturer:: Nexperia USA Inc.

Package:: 16-SSOP (0.209, 5.30mm Width)

Datasheet:: HEF4051BTS,112.pdf

Description:: IC MUX/DEMUX 8X1 16SSOP

In Stock:: 3837

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HEF4051BTS,112 Specifications

Package/Case:
16-SSOP (0.209, 5.30mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Obsolete
SwitchCircuit:
-
Multiplexer/DemultiplexerCircuit:
8:1
NumberofCircuits:
1
On-StateResistance(Max):
155Ohm
Channel-to-ChannelMatching(ΔRon):
5Ohm
Voltage-SupplySingle(V+):
3V ~ 15V
Voltage-SupplyDual(V±):
-
SwitchTime(TonToff)(Max):
-
-3dbBandwidth:
70MHz
ChargeInjection:
-
ChannelCapacitance(CS(off)CD(off)):
7.5pF
Current-Leakage(IS(off))(Max):
200nA
Crosstalk:
-50dB @ 1MHz
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount

HEF4051BTS,112 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including HEF4051BTS,112 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for HEF4051BTS,112 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

HEF4051BTS,112 information

Views：

HEF4051BTS,112 Typical application Circuitry

HEF4051BTS,112

The HEF4051BTS,112 is a versatile 8-channel analog multiplexer/demultiplexer. When connecting this IC in your circuit, it's crucial to be aware of each pin's role. Let's delve into the pin-by-pin connections for the HEF4051BTS,112.

1. Power Pins:

- Connect the VDD pin of the HEF4051BTS,112 to the positive voltage supply, which could be up to +15V, depending on your application needs.

- Link the VSS pin directly to the ground (0V) to complete the power configuration.

2. Signal Channels: The HEF4051BTS,112 boasts 8 input/output channels labeled Y0 to Y7. These channels are where you either introduce the signals you desire to multiplex or obtain demultiplexed signals.

3. Common I/O: The Z pin on the HEF4051BTS,112 serves a dual role. In a multiplexing setup, it acts as the aggregated output. Conversely, in a demultiplexing scenario, it functions as the input source.

4. Channel Selection: The HEF4051BTS,112 employs three binary control pins: A0, A1, and A2. By adjusting the logic levels (high or low) of these pins, you dictate which of the 8 channels (Y0-Y7) connects to the Z pin. For clarity, a binary code of 010 on A0, A1, and A2 respectively would activate channel Y2.

5. Inhibit Operation: The "Inhibit" (labeled as INH) pin on the HEF4051BTS,112 is a standout feature. When activated with a high voltage level, it disconnects all channels from the Z pin, rendering the multiplexer/demultiplexer inactive.

6. Negative Voltage Reference: For the HEF4051BTS,112 to handle signals that possess negative voltage swings below ground, you should link the VEE pin to the negative supply voltage. If your signals remain above ground, simply connect VEE to your ground.

7.Key Considerations:

- For the HEF4051BTS,112 to function optimally, never leave any unused inputs in a floating state. Always anchor them to a known logic level, either VDD or VSS.

- Introducing capacitors between the VDD and VSS pins, in close proximity to the HEF4051BTS,112, can improve stability by acting as decoupling capacitors.

- As with most CMOS devices, the HEF4051BTS,112 is susceptible to static discharge. Thus, implementing standard anti-static precautions during handling is prudent.

In conclusion, always consult the HEF4051BTS,112 datasheet for a comprehensive overview and more intricate circuit examples. It's a valuable resource for ensuring reliable and efficient usage of this IC.
