Nexperia USA Inc. HEF4051BT,013

Part No.:: HEF4051BT,013

Manufacturer:: Nexperia USA Inc.

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: HEF4051BT,013.pdf

Description:: IC MUX/DEMUX 8X1 16SOIC

In Stock:: 3311

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

HEF4051BT,013 Specifications

Package/Case:
16-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Bulk,Bulk
Series:
-
ProductStatus:
Discontinued at Mosen
SwitchCircuit:
-
Multiplexer/DemultiplexerCircuit:
8:1
NumberofCircuits:
1
On-StateResistance(Max):
155Ohm
Channel-to-ChannelMatching(ΔRon):
5Ohm
Voltage-SupplySingle(V+):
3V ~ 15V
Voltage-SupplyDual(V±):
-
SwitchTime(TonToff)(Max):
-
-3dbBandwidth:
70MHz
ChargeInjection:
-
ChannelCapacitance(CS(off)CD(off)):
7.5pF
Current-Leakage(IS(off))(Max):
200nA
Crosstalk:
-50dB @ 1MHz
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount

HEF4051BT,013 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including HEF4051BT,013 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for HEF4051BT,013 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

HEF4051BT,013 information

Views：

HEF4051BT,013 Typical application Circuitry

HEF4051BT,013

The HEF4051BT,013 is a distinctive 8-channel analog multiplexer/demultiplexer. Ensuring the correct connection down to each individual pin is paramount. Here's how you go about it:

1. Powering Up:

- The VDD terminal of the HEF4051BT,013 should be linked to the positive end of your supply voltage, potentially as high as +15V based on your setup requirements.

- Conversely, the VSS terminal must be grounded, ensuring a common reference for your circuit.

2. Channel Configuration: The HEF4051BT,013 encompasses 8 distinguishable channels labeled as Y0 through Y7. This is where your signal sources will connect for multiplexing or where you'll fetch demultiplexed outputs.

3. Central I/O Terminal: The HEF4051BT,013 features a Z terminal, which plays a dual role. In multiplexing mode, this acts as the consolidated output. It becomes your main input if you're demultiplexing.

4. Commanding the Channel: Directing the behavior of the HEF4051BT,013 is achieved through three binary control terminals: A0, A1, and A2. Altering their logic states (high/low) stipulates the active channel connecting to the Z terminal. For instance, providing a 001 binary input across A0, A1, and A2 will engage the Y1 channel.

5. Overriding Functionality: The HEF4051BT,013 comes equipped with an "Inhibit" function, denoted by the INH terminal. A high voltage signal here overrides other operations and disconnects all channels from the Z terminal.

6. Handling Negative Signals: The VEE terminal of the HEF4051BT,013 is where you'd connect a negative supply if your signals have voltage swings below the ground. If not, this terminal can simply be linked to the ground.

7.Essential Notes:

- The stability of the HEF4051BT,013 can be greatly improved by introducing decoupling capacitors between the VDD and VSS terminals, situated close to the IC.

- While the HEF4051BT,013 showcases robust capabilities, it shares the typical CMOS sensitivity to static. Employing standard precautions during manipulation is highly advised.

- Keeping unused pins floating isn't a good practice. Anchor them to a recognized voltage level, either to VDD or VSS.

To wrap up, the HEF4051BT,013 datasheet remains an invaluable reference. It offers a more exhaustive exploration of the chip's capabilities and provides detailed schematic examples for diverse applications.
