FTDI, Future Technology Devices International Ltd FT232HL-TRAY

Part No.:: FT232HL-TRAY

Manufacturer:: FTDI, Future Technology Devices International Ltd

Package:: 48-LQFP

Datasheet:: FT232HL-TRAY.pdf

Description:: IC HS USB TO UART/FIFO 48LQFP

In Stock:: 2330

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FT232HL-TRAY Specifications

Package/Case:
48-LQFP
Packaging:
Tray
Series:
-
ProductStatus:
Active
Protocol:
USB
Function:
Bridge, USB to UART,FIFO
Interface:
UART, FIFO
Standards:
USB 2.0
Voltage-Supply:
1.62V ~ 1.98V, 2.97V ~ 3.63V
Current-Supply:
24mA
OperatingTemperature:
-40°C ~ 85°C
