Infineon Technologies FS150R12KT4B9BOSA1

Part No.:: FS150R12KT4B9BOSA1

Manufacturer:: Infineon Technologies

Package:: Module

Datasheet:: FS150R12KT4B9BOSA1.pdf

Description:: IGBT MOD 1200V 150A 750W

In Stock:: 3495

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FS150R12KT4B9BOSA1 Specifications

Packaging:
Tray
Series:
EconoPACK™ 3
ProductStatus:
Active
IGBTType:
Trench Field Stop
Configuration:
Three Phase Inverter
Voltage-CollectorEmitterBreakdown(Max):
1200 V
Current-Collector(Ic)(Max):
150 A
Power-Max:
750 W
Vce(on)(Max)@VgeIc:
2.1V @ 15V, 150A
Current-CollectorCutoff(Max):
1 mA
InputCapacitance(Cies)@Vce:
9.35 nF @ 25 V
Input:
Standard
NTCThermistor:
No
OperatingTemperature:
-40°C ~ 150°C
MountingType:
Chassis Mount
