ON Semiconductor FODM8801CR2

Part No.:: FODM8801CR2

Manufacturer:: ON Semiconductor

Package:: 4-SOIC (0.173, 4.40mm Width)

Datasheet:: FODM8801CR2.pdf

Description:: OPTOISO 3.75KV TRANS 4-MINI-FLAT

In Stock:: 2031

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FODM8801CR2 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
OptoHit™
ProductStatus:
Active
NumberofChannels:
1
Voltage-Isolation:
3750Vrms
CurrentTransferRatio(Min):
200% @ 1mA
CurrentTransferRatio(Max):
400% @ 1mA
TurnOn/TurnOffTime(Typ):
6µs, 6µs
Rise/FallTime(Typ):
5µs, 5.5µs
InputType:
DC
OutputType:
Transistor
Voltage-Output(Max):
75V
Current-Output/Channel:
30mA
Voltage-Forward(Vf)(Typ):
1.35V
Current-DCForward(If)(Max):
20 mA
VceSaturation(Max):
400mV
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
