Name: FM25L16B-G
Brand: Cypress Semiconductor Corp
SKU: FM25L16B-G
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Cypress Semiconductor Corp FM25L16B-G

Part No.:: FM25L16B-G

Manufacturer:: Cypress Semiconductor Corp

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: FM25L16B-G.pdf

Description:: IC FRAM 16KBIT SPI 20MHZ 8SOIC

In Stock:: 3970

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FM25L16B-G Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Bulk,Tube
Series:
F-RAM™
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FRAM
Technology:
FRAM (Ferroelectric RAM)
MemorySize:
16Kb (2K x 8)
MemoryInterface:
SPI
ClockFrequency:
20 MHz
WriteCycleTime-WordPage:
-
AccessTime:
-
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
