Cypress Semiconductor Corp FM22L16-55-TG

Part No.:: FM22L16-55-TG

Manufacturer:: Cypress Semiconductor Corp

Package:: 44-TSOP (0.400, 10.16mm Width)

Datasheet:: FM22L16-55-TG.pdf

Description:: IC FRAM 4MBIT PARALLEL 44TSOP II

In Stock:: 3979

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

FM22L16-55-TG Specifications

Package/Case:
44-TSOP (0.400, 10.16mm Width)
Packaging:
Tray,Tray
Series:
F-RAM™
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FRAM
Technology:
FRAM (Ferroelectric RAM)
MemorySize:
4Mb (256K x 16)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
110ns
AccessTime:
110 ns
Voltage-Supply:
2.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
