Infineon Technologies F3L300R07PE4BOSA1

Part No.:: F3L300R07PE4BOSA1

Manufacturer:: Infineon Technologies

Package:: Module

Datasheet:: F3L300R07PE4BOSA1.pdf

Description:: IGBT MOD 650V 300A 940W

In Stock:: 3910

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

F3L300R07PE4BOSA1 Specifications

Packaging:
Bulk,Tray
Series:
EconoPACK™ 4
ProductStatus:
Active
IGBTType:
Trench Field Stop
Configuration:
Three Level Inverter
Voltage-CollectorEmitterBreakdown(Max):
650 V
Current-Collector(Ic)(Max):
300 A
Power-Max:
940 W
Vce(on)(Max)@VgeIc:
1.95V @ 15V, 300A
Current-CollectorCutoff(Max):
1 mA
InputCapacitance(Cies)@Vce:
18.5 nF @ 25 V
Input:
Standard
NTCThermistor:
Yes
OperatingTemperature:
-40°C ~ 150°C
MountingType:
Chassis Mount
