Texas Instruments F280049PZSR

Part No.:: F280049PZSR

Manufacturer:: Texas Instruments

Package:: 100-LQFP

Datasheet:: F280049PZSR.pdf

Description:: IC MCU 32BIT 256KB FLASH 100LQFP

In Stock:: 3673

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

F280049PZSR Specifications

Package/Case:
100-LQFP
Packaging:
Tape & Reel (TR)
Series:
C2000™ C28x Piccolo™
RoHS:
RoHS
Speed:
100MHz
RAM Size:
100K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
CANbus, I²C, LINbus, SCI, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
40
Core Processor:
C28x
Data Converters:
A/D 21x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
256KB (256K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TJ)
