Texas Instruments F280025CPTQR

Part No.:: F280025CPTQR

Manufacturer:: Texas Instruments

Package:: 48-LQFP

Datasheet:

Description:: IC MCU 32BIT 128KB FLASH 48LQFP

In Stock:: 303

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

F280025CPTQR Specifications

Package/Case:
48-LQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100, F28002x C2000™
RoHS:
RoHS
Speed:
100MHz
RAM Size:
12K x 16
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
CANbus, I²C, LINbus, SCI, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
14
Core Processor:
C28x
Data Converters:
A/D 14x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
128KB (64K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
