Name: DSPIC33EV128GM106-E/PT
Brand: Microchip Technology
SKU: DSPIC33EV128GM106-E/PT
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology DSPIC33EV128GM106-E/PT

Part No.:: DSPIC33EV128GM106-E/PT

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: DSPIC33EV128GM106-E/PT.pdf

Description:: IC MCU 16BIT 128KB FLASH 64TQFP

In Stock:: 3794

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DSPIC33EV128GM106-E/PT Specifications

Package/Case:
64-TQFP
Packaging:
Tray
Series:
Automotive, AEC-Q100, dsPIC™ 33EV, Functional Safety (FuSa)
RoHS:
RoHS
Speed:
60 MIPs
RAM Size:
8K x 8
Core Size:
16-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Connectivity:
CANbus, I²C, IrDA, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
53
Core Processor:
dsPIC
Data Converters:
A/D 36x10/12b
Oscillator Type:
Internal
Program Memory Size:
128KB (43K x 24)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 125°C (TA)
