Name: DSPIC30F3014-30I/PT
Brand: Microchip Technology
SKU: DSPIC30F3014-30I/PT
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology DSPIC30F3014-30I/PT

Part No.:: DSPIC30F3014-30I/PT

Manufacturer:: Microchip Technology

Package:: 44-TQFP

Datasheet:: DSPIC30F3014-30I/PT.pdf

Description:: IC MCU 16BIT 24KB FLASH 44TQFP

In Stock:: 2638

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DSPIC30F3014-30I/PT Specifications

Package/Case:
44-TQFP
Packaging:
Tray
Series:
dsPIC™ 30F
RoHS:
RoHS
Speed:
30 MIPs
RAM Size:
2K x 8
Core Size:
16-Bit
EEPROM Size:
1K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
30
Core Processor:
dsPIC
Data Converters:
A/D 13x12b
Oscillator Type:
Internal
Program Memory Size:
24KB (8K x 24)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
