Analog Devices Inc./Maxim Integrated DS1821S

Part No.:: DS1821S

Manufacturer:: Analog Devices Inc./Maxim Integrated

Package:: 8-SOIC (0.209, 5.30mm Width)

Datasheet:: DS1821S.pdf

Description:: SENSOR DIGITAL -55C-125C 8SO

In Stock:: 2994

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DS1821S Specifications

Packaging:
Tube
Series:
-
ProductStatus:
Obsolete
SensorType:
Digital, Local
SensingTemperature-Local:
-55°C ~ 125°C
SensingTemperature-Remote:
-
OutputType:
1-Wire®
Voltage-Supply:
2.7V ~ 5.5V
Resolution:
8 b
Features:
One-Shot, Output Switch, Programmable Limit, Standby Mode
Accuracy-Highest(Lowest):
±1°C
TestCondition:
0°C ~ 85°C
OperatingTemperature:
-55°C ~ 125°C
MountingType:
Surface Mount

DS1821S this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including DS1821S price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for DS1821S to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

DS1821S information

Views：

DS1821S Typical application Circuitry

DS1821S

The DS1821S is a Programmable Digital Thermometer and Thermostat chip developed by Maxim Integrated. This versatile device combines the functionality of precise temperature measurement with the capability of setting programmable temperature thresholds, which can trigger thermostat actions. It's designed for a wide range of applications requiring temperature monitoring and control, such as environmental controls, system thermal management, and consumer appliances.

Key Features and Parameters:

- Temperature Range: The DS1821S can measure temperatures from -55°C to +125°C, providing flexibility for diverse applications.

- Programmable Resolution: It offers adjustable resolution from 9 to 12 bits, allowing users to optimize between measurement precision and conversion speed.

- Programmable Thermostat Function: Includes the ability to set high and low temperature thresholds, enabling it to act as a standalone thermostat.

- 1-Wire Interface: Simplifies communication and power with a single wire, reducing the complexity and cost of wiring in embedded applications.

- Non-Volatile Memory: Settings such as temperature limits are stored in non-volatile memory, preserving configurations across power cycles.

Application Scenario – Smart Home Heating System:

In a smart home heating system, the DS1821S can be utilized to monitor room temperatures and control heating elements dynamically, ensuring efficient energy usage while maintaining comfort.

Circuit Design Details:

1. Power and Communication:

- DQ (Pin 1): This pin serves as the communication line for the 1-Wire interface and can also deliver power to the device in a parasitic power configuration. Connect DQ to a digital I/O pin on a microcontroller. A 4.7kΩ pull-up resistor is essential, connecting DQ to the +5V power line to ensure proper logic levels and power supply.

2. Ground Connection:

- GND (Pin 2): Connect this pin directly to the system's ground. This ensures a common ground reference for accurate temperature measurement and device stability.

3. Optional External Power Supply:

- VDD (Pin 3): While the DS1821S can operate in a parasitic power mode through the DQ pin, connecting VDD to a +5V supply can enhance device performance, especially in environments with high electrical noise. Use a 0.1µF decoupling capacitor close to VDD to filter out voltage spikes.

Design Considerations:

- 1-Wire Bus Configuration: When integrating the DS1821S into a system with multiple 1-Wire devices, careful attention to bus topology and cable lengths is required to maintain reliable communication.

- Environmental Conditions: The placement of the DS1821S should be strategic to avoid proximity to heat sources that could affect its temperature readings. Consider using a small, thermally conductive enclosure to shield it from external thermal interference.

- Electrical Noise: In applications with significant electrical noise, additional filtering on the DQ line may be necessary to ensure reliable 1-Wire communication.

- Software Integration: Developing software that accurately reads temperature data, configures thermostat settings, and responds to temperature threshold events is crucial for maximizing the DS1821S's capabilities in a smart heating system.

- Power Supply Considerations: In systems where the DS1821S is powered parasitically, ensure the microcontroller's I/O pin can provide sufficient current for stable operation. In configurations using external power (VDD), verify that the power supply can maintain a stable +5V, even under varying load conditions.

Employing the DS1821S in a smart home heating system not only enhances the system's responsiveness to temperature changes but also promotes energy efficiency by providing precise control over heating elements based on actual room temperatures. This application highlights the DS1821S's utility in creating more intelligent and responsive environmental control systems, underscoring its value in modern smart home technologies.
