Texas Instruments DRV8906QPWPRQ1

Part No.:: DRV8906QPWPRQ1

Manufacturer:: Texas Instruments

Package:: 24-TSSOP (0.173, 4.40mm Width) Exposed Pad

Datasheet:: DRV8906QPWPRQ1.pdf

Description:: AUTO MULTI-CHANNEL HALF BRIDGER

In Stock:: 3865

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DRV8906QPWPRQ1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
OutputConfiguration:
Half Bridge (6)
Applications:
DC Motors, General Purpose
Interface:
Logic, PWM, SPI
LoadType:
Inductive, Capacitive, Resistive
Technology:
MOSFET (Metal Oxide)
RdsOn(Typ):
750mOhm LS, 750mOhm HS
Current-Output/Channel:
6A
Current-PeakOutput:
-
Voltage-Supply:
3V ~ 5.5V
Voltage-Load:
3V ~ 5.5V
OperatingTemperature:
-40°C ~ 150°C (TJ)
Features:
Charge Pump, Slew Rate Controlled
FaultProtection:
Over Current, Over Voltage, UVLO
MountingType:
Surface Mount
