Texas Instruments DRV8876QPWPRQ1

Part No.:: DRV8876QPWPRQ1

Manufacturer:: Texas Instruments

Package:: 16-TSSOP (0.173, 4.40mm Width) Exposed Pad

Datasheet:

Description:: IC MOTOR DRIVER

In Stock:: 2158

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DRV8876QPWPRQ1 Specifications

Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q100
ProductStatus:
Active
MotorType-Stepper:
Bipolar
MotorType-ACDC:
Brushed DC
Function:
Driver - Fully Integrated, Control and Power Stage
OutputConfiguration:
Half Bridge (2)
Interface:
PWM
Technology:
NMOS
StepResolution:
-
Applications:
General Purpose
Current-Output:
3.5A
Voltage-Supply:
4.5V ~ 37V
Voltage-Load:
4.5V ~ 37V
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
