Texas Instruments DP83867ISRGZT

Part No.:: DP83867ISRGZT

Manufacturer:: Texas Instruments

Package:: 48-VFQFN Exposed Pad

Datasheet:: DP83867ISRGZT.pdf

Description:: IC ETHERNET PHY 48VQFN

In Stock:: 3368

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DP83867ISRGZT Specifications

Package/Case:
48-VFQFN Exposed Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Protocol:
Ethernet
Function:
Physical Layer Controller
Interface:
Serial
Standards:
10/100/1000 Base-TX PHY
Voltage-Supply:
2.375V ~ 2.625V, 1.71V ~ 1.89V, 0.95V ~ 1.155V
Current-Supply:
157mA
OperatingTemperature:
-40°C ~ 85°C
