Vishay Siliconix DG408DY-T1

Part No.:: DG408DY-T1

Manufacturer:: Vishay Siliconix

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: DG408DY-T1.pdf

Description:: IC MUX CMOS ANG DUAL 8CH 16SOIC

In Stock:: 3060

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

DG408DY-T1 Specifications

Package/Case:
16-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
SwitchCircuit:
-
Multiplexer/DemultiplexerCircuit:
8:1
NumberofCircuits:
1
On-StateResistance(Max):
100Ohm
Channel-to-ChannelMatching(ΔRon):
15Ohm (Max)
Voltage-SupplySingle(V+):
12V
Voltage-SupplyDual(V±):
±5V ~ 20V
SwitchTime(TonToff)(Max):
150ns, 150ns
-3dbBandwidth:
-
ChargeInjection:
20pC
ChannelCapacitance(CS(off)CD(off)):
3pF, 26pF
Current-Leakage(IS(off))(Max):
500pA
Crosstalk:
-
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
