Cypress Semiconductor Corp CY8C4248LQI-BL583T

Part No.:: CY8C4248LQI-BL583T

Manufacturer:: Cypress Semiconductor Corp

Package:: 56-UFQFN Exposed Pad

Datasheet:: CY8C4248LQI-BL583T.pdf

Description:: IC MCU 32BIT 256KB FLASH 56QFN

In Stock:: 3899

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CY8C4248LQI-BL583T Specifications

Package/Case:
56-UFQFN Exposed Pad
Packaging:
Tape & Reel (TR)
Series:
PSOC® 4 CY8C4xx8 BLE
RoHS:
RoHS
Speed:
48MHz
RAM Size:
32K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Bluetooth, Brown-out Detect/Reset, Cap Sense, DMA LCD, LVD, POR, PWM, SmartCard, SmartSense, WDT
Connectivity:
I²C, IrDA, LINbus, Microwire, SmartCard, SPI, SSP, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
36
Core Processor:
ARM® Cortex®-M0
Data Converters:
A/D 16x12b SAR; D/A 2xIDAC
Oscillator Type:
Internal
Program Memory Size:
256KB (256K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
