Cypress Semiconductor Corp CY8C4146AZI-S455

Part No.:: CY8C4146AZI-S455

Manufacturer:: Cypress Semiconductor Corp

Package:: 64-LQFP

Datasheet:: CY8C4146AZI-S455.pdf

Description:: IC MCU 32BIT 64KB FLASH 64TQFP

In Stock:: 2794

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CY8C4146AZI-S455 Specifications

Package/Case:
64-LQFP
Packaging:
Tray
Series:
PSOC® 4 CY8C4100S Plus
RoHS:
RoHS
Speed:
48MHz
RAM Size:
8K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, CapSense, LCD, POR, PWM, WDT
Connectivity:
I²C, IrDA, LINbus, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
54
Core Processor:
ARM® Cortex®-M0+
Data Converters:
A/D 16x10b Slope, 16x12b SAR; D/A 2xIDAC
Oscillator Type:
Internal
Program Memory Size:
64KB (64K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
