Name: CY8C4014SXI-420T
Brand: Cypress Semiconductor Corp
SKU: CY8C4014SXI-420T
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Cypress Semiconductor Corp CY8C4014SXI-420T

Part No.:: CY8C4014SXI-420T

Manufacturer:: Cypress Semiconductor Corp

Package:: 8-SOIC (0.154", 3.90mm Width)

Datasheet:: CY8C4014SXI-420T.pdf

Description:: IC MCU 32BIT 16KB FLASH 8SOIC

In Stock:: 3392

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CY8C4014SXI-420T Specifications

Package/Case:
8-SOIC (0.154", 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
PSOC® 4 CY8C4000
RoHS:
RoHS
Speed:
16MHz
RAM Size:
2K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C
Mounting Type:
Surface Mount
Number of I/O:
5
Core Processor:
ARM® Cortex®-M0
Data Converters:
D/A 1x7b, 1x8b
Oscillator Type:
Internal
Program Memory Size:
16KB (16K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
