Cypress Semiconductor Corp CY8C27443-24PVXIT

Part No.:: CY8C27443-24PVXIT

Manufacturer:: Cypress Semiconductor Corp

Package:: 28-SSOP (0.209", 5.30mm Width)

Datasheet:: CY8C27443-24PVXIT.pdf

Description:: IC MCU 8BIT 16KB FLASH 28SSOP

In Stock:: 3652

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CY8C27443-24PVXIT Specifications

Package/Case:
28-SSOP (0.209", 5.30mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
PSOC®1 CY8C27xxx
RoHS:
RoHS
Speed:
24MHz
RAM Size:
256 x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
24
Core Processor:
M8C
Data Converters:
A/D 4x14b; D/A 4x9b
Oscillator Type:
Internal
Program Memory Size:
16KB (16K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
