Cypress Semiconductor Corp CY7C65631-56LTXC

Part No.:: CY7C65631-56LTXC

Manufacturer:: Cypress Semiconductor Corp

Package:: 56-VFQFN Exposed Pad

Datasheet:: CY7C65631-56LTXC.pdf

Description:: IC USB CTLR 2.0 4PORT AEC 56QFN

In Stock:: 2094

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CY7C65631-56LTXC Specifications

Package/Case:
56-VFQFN Exposed Pad
Packaging:
Bulk,Tray
Series:
EZ-USB HX2LP Lite™
ProductStatus:
Active
Protocol:
USB
Function:
Hub Controller
Interface:
USB
Standards:
USB 2.0
Voltage-Supply:
3.15V ~ 3.45V
Current-Supply:
-
OperatingTemperature:
0°C ~ 70°C
