Silicon Labs CP2102N-A01-GQFN24

Part No.:: CP2102N-A01-GQFN24

Manufacturer:: Silicon Labs

Package:: 24-WFQFN Exposed Pad

Datasheet:: CP2102N-A01-GQFN24.pdf

Description:: IC BRIDGE USB TO UART 24QFN

In Stock:: 2907

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CP2102N-A01-GQFN24 Specifications

Package/Case:
24-WFQFN Exposed Pad
Packaging:
Tube
Series:
USBXpress™
ProductStatus:
Obsolete
Protocol:
USB
Function:
Bridge, USB to UART
Interface:
UART
Standards:
USB 2.0
Voltage-Supply:
3V ~ 3.6V
Current-Supply:
9.5mA
OperatingTemperature:
-40°C ~ 85°C
