Name: CAT25160VI-GT3
Brand: ON Semiconductor
SKU: CAT25160VI-GT3
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

ON Semiconductor CAT25160VI-GT3

Part No.:: CAT25160VI-GT3

Manufacturer:: ON Semiconductor

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: CAT25160VI-GT3.pdf

Description:: IC EEPROM 16KBIT SPI 20MHZ 8SOIC

In Stock:: 3527

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

CAT25160VI-GT3 Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
EEPROM
Technology:
EEPROM
MemorySize:
16Kb (2K x 8)
MemoryInterface:
SPI
ClockFrequency:
20 MHz
WriteCycleTime-WordPage:
5ms
AccessTime:
-
Voltage-Supply:
1.8V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
