Silicon Labs C8051F310-GQR

Part No.:: C8051F310-GQR

Manufacturer:: Silicon Labs

Package:: 32-LQFP

Datasheet:: C8051F310-GQR.pdf

Description:: IC MCU 8BIT 16KB FLASH 32LQFP

In Stock:: 3688

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

C8051F310-GQR Specifications

Package/Case:
32-LQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
C8051F31x
RoHS:
RoHS
Speed:
25MHz
RAM Size:
1.25K x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Not For New Designs
Peripherals:
POR, PWM, Temp Sensor, WDT
Connectivity:
SMBus (2-Wire/I²C), SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
29
Core Processor:
8051
Data Converters:
A/D 21x10b
Oscillator Type:
Internal
Program Memory Size:
16KB (16K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
