Silicon Labs C8051F133-GQ

Part No.:: C8051F133-GQ

Manufacturer:: Silicon Labs

Package:: 64-TQFP

Datasheet:: C8051F133-GQ.pdf

Description:: IC MCU 8BIT 64KB FLASH 64TQFP

In Stock:: 511

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

C8051F133-GQ Specifications

Package/Case:
64-TQFP
Packaging:
Tray
Series:
C8051F13x
RoHS:
RoHS
Speed:
100MHz
RAM Size:
8.25K x 8
Core Size:
8-Bit
EEPROM Size:
-
Part Status:
Not For New Designs
Peripherals:
Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT
Connectivity:
EBI/EMI, SMBus (2-Wire/I²C), SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
32
Core Processor:
8051
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
64KB (64K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
