Infineon Technologies BTN7960BAUMA1

Part No.:: BTN7960BAUMA1

Manufacturer:: Infineon Technologies

Package:: TO-263-8, D²Pak (7 Leads + Tab), TO-263CA

Datasheet:: BTN7960BAUMA1.pdf

Description:: IC MOTOR DRIVER 8V-18V TO263-7

In Stock:: 2570

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BTN7960BAUMA1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
NovalithIC™
ProductStatus:
Obsolete
MotorType-Stepper:
-
MotorType-ACDC:
Brushed DC
Function:
Driver - Fully Integrated, Control and Power Stage
OutputConfiguration:
Half Bridge
Interface:
On/Off
Technology:
Power MOSFET
StepResolution:
-
Applications:
General Purpose
Current-Output:
47A
Voltage-Supply:
8V ~ 18V
Voltage-Load:
8V ~ 18V
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount
