Name: BAW56W-QF
Brand: Nexperia USA Inc.
SKU: BAW56W-QF
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Nexperia USA Inc. BAW56W-QF

Part No.:: BAW56W-QF

Manufacturer:: Nexperia USA Inc.

Package:: SC-70, SOT-323

Datasheet:: BAW56W-QF.pdf

Description:: TRANS PREBIAS NPN/PNP

In Stock:: 2418

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAW56W-QF Specifications

Packaging:
Bulk
Series:
Automotive, AEC-Q101
ProductStatus:
Active
DiodeConfiguration:
1 Pair Common Anode
DiodeType:
Standard
Voltage-DCReverse(Vr)(Max):
90 V
Current-AverageRectified(Io)(perDiode):
150mA (DC)
Voltage-Forward(Vf)(Max)@If:
1.25 V @ 150 mA
Speed:
Small Signal =< 200mA (Io), Any Speed
ReverseRecoveryTime(trr):
4 ns
Current-ReverseLeakage@Vr:
500 nA @ 80 V
OperatingTemperature-Junction:
150°C
MountingType:
Surface Mount

BAW56W-QF this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including BAW56W-QF price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for BAW56W-QF to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

BAW56W-QF information

Views：

BAW56W-QF Typical application Circuitry

BAW56W-QF

The BAW56W-QF is a high-speed switching diode array designed for general-purpose and automotive applications. Compact electrical designs can benefit greatly from its twin common anode layout and small SOT323 (SC-70) Surface-Mounted Device (SMD) plastic package. Key specifications of the BAW56W-QF include:

1. High Switching Speed: The diode boasts a reverse recovery time (trr) of 4 ns, which is ideal for fast switching applications.

2. Low Capacitance: With a capacitance (Cd) of ≤ 2 pF, it's suitable for high-frequency circuits.

3. Low Leakage Current: Ensures efficient performance with minimal power waste.

4. Reverse Voltage: The maximum reverse voltage (Vr) is up to 90 V.

5. Current Rating: Every diode has an average rectified current (Io) of 150mA.

Application Scenario: Signal Routing in Automotive Electronics

The BAW56W-QF is commonly used in automotive electronics for signal routing. Here's a detailed explanation of such an application:

1. Power Supply Connection: Connect a suitable power source to the common anode of the diode. Ensure the supply voltage is within the diode's maximum reverse voltage of 90 V.

2. Signal Inputs: Connect two different signal sources to the cathodes of the diode. These could be from sensors or control units within the automotive system.

3. Output Connection: The output from the anode can be connected to a microcontroller or another processing unit that interprets the signals.

4. Current Limiting: Include resistors in series with the signal sources to limit the current through the diodes, ensuring it doesn't exceed 150mA.

5. Noise Reduction: A capacitor may be placed parallel to the diode for filtering out any potential noise in the signal.

6. Circuit Protection: Consider adding protection elements like a transient voltage suppressor (TVS) diode to safeguard against voltage spikes.

Design Considerations

When designing a circuit with the BAW56W-QF, consider:

- Voltage and Current Limits: Adhere to the specified maximum voltage and current ratings.

- Thermal Management: Although the diode is efficient, ensure proper heat dissipation, especially in compact or high-power designs.

- Signal Integrity: Minimize lead lengths and avoid layout configurations that could introduce interference, crucial in high-speed applications.

In conclusion, the BAW56W-QF is a versatile diode array suitable for high-speed switching, particularly in automotive applications, where its fast response time and compact form factor are advantageous.
