Nexperia USA Inc. BAV99W-QX

Part No.:: BAV99W-QX

Manufacturer:: Nexperia USA Inc.

Package:: SC-70, SOT-323

Datasheet:: BAV99W-QX.pdf

Description:: TRANS PREBIAS NPN/PNP

In Stock:: 3860

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAV99W-QX Specifications

Packaging:
Bulk
Series:
Automotive, AEC-Q101
ProductStatus:
Active
DiodeConfiguration:
1 Pair Series Connection
DiodeType:
Standard
Voltage-DCReverse(Vr)(Max):
100 V
Current-AverageRectified(Io)(perDiode):
150mA (DC)
Voltage-Forward(Vf)(Max)@If:
1.25 V @ 150 mA
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
ReverseRecoveryTime(trr):
4 ns
Current-ReverseLeakage@Vr:
500 nA @ 80 V
OperatingTemperature-Junction:
150°C
MountingType:
Surface Mount
