Rohm Semiconductor BAV99FT116

Part No.:: BAV99FT116

Manufacturer:: Rohm Semiconductor

Package:: TO-236-3, SC-59, SOT-23-3

Datasheet:

Description:: DIODE GENERAL PURPOSE SMD

In Stock:: 2939

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAV99FT116 Specifications

Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Obsolete
DiodeConfiguration:
1 Pair Series Connection
DiodeType:
Standard
Voltage-DCReverse(Vr)(Max):
75 V
Current-AverageRectified(Io)(perDiode):
215mA (DC)
Voltage-Forward(Vf)(Max)@If:
1.25 V @ 150 mA
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
ReverseRecoveryTime(trr):
4 ns
Current-ReverseLeakage@Vr:
1 µA @ 75 V
OperatingTemperature-Junction:
150°C (Max)
MountingType:
Surface Mount

BAV99FT116 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including BAV99FT116 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for BAV99FT116 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

BAV99FT116 information

Views：

BAV99FT116 Typical application Circuitry

BAV99FT116

A semiconductor device specifically made to function as a high-speed switching diode is the BAV99FT116. Because of its effectiveness in quick signal transfer, it is widely used in many different types of electronic circuits. This component is essential in applications where quick and reliable switching is necessary. Let's delve into its application scenarios, parameter features, and provide a comprehensive guide to circuit connection for a specific use case.

Function and Application Scenarios

BAV99FT116 is used in:

- High-Frequency Switching Circuits: Ideal for applications requiring rapid transitions, such as RF (radio frequency) circuits.

- Signal Processing: In both digital and analog signal processing where quick switching is crucial.

- Voltage Clamping: Used to shield delicate electronic circuit components from brief voltage spikes.

Parameter Characteristics

- Fast Switching Ability: The BAV99FT116 is optimized for high-speed operations.

- Low Forward Voltage Drop: This ensures the diode operates efficiently, minimizing power loss.

- Compact Design: Frequently features a dual-diode configuration, beneficial for space-saving in circuit layouts.

Application Example: RF Switching Circuit

Circuit Connection Details

- Input Signal Connection: Attach the RF signal to the anode of the first diode in the BAV99FT116.

- Output Arrangement: The output is obtained from the junction point between the cathode of the first diode and a connecting load resistor.

- Stable Grounding: Connect the cathode of the second diode in the BAV99FT116 to the ground for circuit stability.

Circuit Design Considerations

1. Operating Voltage: Ensure that the voltage levels in the circuit are within the tolerable range of the BAV99FT116.

2. Thermal Considerations: Proper heat management is crucial to prevent overheating in high-speed switching.

3. Signal Clarity: Maintain signal integrity, particularly important in high-frequency RF applications.

4. Circuit Layout: A well-thought-out layout is necessary to minimize interference and optimize performance.

To sum up, the BAV99FT116 is a great option for high-speed switching applications including digital signal processing and RF circuits. Its efficiency, characterized by a low forward voltage drop and a dual-diode configuration, makes it suitable for creating compact and energy-efficient electronic designs.
