Nexperia USA Inc. BAV70W,115

Part No.:: BAV70W,115

Manufacturer:: Nexperia USA Inc.

Package:: SC-70, SOT-323

Datasheet:: BAV70W,115.pdf

Description:: DIODE ARRAY GP 100V 175MA SOT323

In Stock:: 3604

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAV70W,115 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
DiodeConfiguration:
1 Pair Common Cathode
DiodeType:
Standard
Voltage-DCReverse(Vr)(Max):
100 V
Current-AverageRectified(Io)(perDiode):
175mA (DC)
Voltage-Forward(Vf)(Max)@If:
1.25 V @ 150 mA
Speed:
Small Signal =< 200mA (Io), Any Speed
ReverseRecoveryTime(trr):
4 ns
Current-ReverseLeakage@Vr:
500 nA @ 80 V
OperatingTemperature-Junction:
150°C (Max)
MountingType:
Surface Mount
