Diodes Incorporated BAV199DW-7-F

Part No.:: BAV199DW-7-F

Manufacturer:: Diodes Incorporated

Package:: 6-TSSOP, SC-88, SOT-363

Datasheet:: BAV199DW-7-F.pdf

Description:: DIODE ARRAY GP 85V 140MA SOT363

In Stock:: 2775

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAV199DW-7-F Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
DiodeConfiguration:
2 Pair Series Connection
DiodeType:
Standard
Voltage-DCReverse(Vr)(Max):
85 V
Current-AverageRectified(Io)(perDiode):
140mA (DC)
Voltage-Forward(Vf)(Max)@If:
1.1 V @ 50 mA
Speed:
Small Signal =< 200mA (Io), Any Speed
ReverseRecoveryTime(trr):
3 µs
Current-ReverseLeakage@Vr:
5 nA @ 75 V
OperatingTemperature-Junction:
-65°C ~ 150°C
MountingType:
Surface Mount
