Comchip Technology BAT54ST-HF

Part No.:: BAT54ST-HF

Manufacturer:: Comchip Technology

Package:: SOT-523

Datasheet:: BAT54ST-HF.pdf

Description:: DIODE SCHOTTKY 30V 0.2A SOT-23

In Stock:: 2818

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAT54ST-HF Specifications

Packaging:
Tape & Reel (TR)
Series:
BAT54xT-HF
ProductStatus:
Active
DiodeConfiguration:
1 Pair Series Connection
DiodeType:
Schottky
Voltage-DCReverse(Vr)(Max):
30 V
Current-AverageRectified(Io)(perDiode):
200mA (DC)
Voltage-Forward(Vf)(Max)@If:
1 V @ 100 mA
Speed:
Small Signal =< 200mA (Io), Any Speed
ReverseRecoveryTime(trr):
5 ns
Current-ReverseLeakage@Vr:
2 µA @ 25 V
OperatingTemperature-Junction:
-55°C ~ 125°C
MountingType:
Surface Mount
