NXP USA Inc. BAS21AVD,165

Part No.:: BAS21AVD,165

Manufacturer:: NXP USA Inc.

Package:: SC-74, SOT-457

Datasheet:

Description:: NOW NEXPERIA BAS21AVD - RECTIFIE

In Stock:: 2893

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAS21AVD,165 Specifications

Packaging:
Bulk
Series:
-
ProductStatus:
Active
DiodeConfiguration:
3 Independent
DiodeType:
Standard
Voltage-DCReverse(Vr)(Max):
200 V
Current-AverageRectified(Io)(perDiode):
200mA (DC)
Voltage-Forward(Vf)(Max)@If:
1.25 V @ 200 mA
Speed:
Small Signal =< 200mA (Io), Any Speed
ReverseRecoveryTime(trr):
50 ns
Current-ReverseLeakage@Vr:
100 nA @ 200 V
OperatingTemperature-Junction:
150°C (Max)
MountingType:
Surface Mount
