Nexperia USA Inc. BAS16VY-QH

Part No.:: BAS16VY-QH

Manufacturer:: Nexperia USA Inc.

Package:: 6-TSSOP, SC-88, SOT-363

Datasheet:: BAS16VY-QH.pdf

Description:: TRANS PREBIAS NPN/PNP

In Stock:: 2654

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

BAS16VY-QH Specifications

Packaging:
Bulk
Series:
Automotive, AEC-Q101
ProductStatus:
Active
DiodeConfiguration:
3 Independent
DiodeType:
Standard
Voltage-DCReverse(Vr)(Max):
100 V
Current-AverageRectified(Io)(perDiode):
200mA (DC)
Voltage-Forward(Vf)(Max)@If:
1.25 V @ 150 mA
Speed:
Small Signal =< 200mA (Io), Any Speed
ReverseRecoveryTime(trr):
4 ns
Current-ReverseLeakage@Vr:
500 nA @ 80 V
OperatingTemperature-Junction:
150°C
MountingType:
Surface Mount
