Microchip Technology ATXMEGA256D3-AUR

Part No.:: ATXMEGA256D3-AUR

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: ATXMEGA256D3-AUR.pdf

Description:: IC MCU 8/16BIT 256KB FLSH 64TQFP

In Stock:: 2921

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATXMEGA256D3-AUR Specifications

Package/Case:
64-TQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
AVR® XMEGA® D3
RoHS:
RoHS
Speed:
32MHz
RAM Size:
16K x 8
Core Size:
8/16-Bit
EEPROM Size:
4K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, IrDA, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
50
Core Processor:
AVR
Data Converters:
A/D 16x12b
Oscillator Type:
Internal
Program Memory Size:
256KB (128K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
