Microchip Technology ATTINY85-20SUR

Part No.:: ATTINY85-20SUR

Manufacturer:: Microchip Technology

Package:: 8-SOIC (0.209", 5.30mm Width)

Datasheet:: ATTINY85-20SUR.pdf

Description:: IC MCU 8BIT 8KB FLASH 8SOIC

In Stock:: 2192

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATTINY85-20SUR Specifications

Package/Case:
8-SOIC (0.209", 5.30mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
AVR® ATtiny, Functional Safety (FuSa)
RoHS:
RoHS
Speed:
20MHz
RAM Size:
512 x 8
Core Size:
8-Bit
EEPROM Size:
512 x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
USI
Mounting Type:
Surface Mount
Number of I/O:
6
Core Processor:
AVR
Data Converters:
A/D 4x10b
Oscillator Type:
Internal
Program Memory Size:
8KB (4K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
