Name: ATTINY85-20PU
Brand: Microchip Technology
SKU: ATTINY85-20PU
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology ATTINY85-20PU

Part No.:: ATTINY85-20PU

Manufacturer:: Microchip Technology

Package:: 8-DIP (0.300", 7.62mm)

Datasheet:: ATTINY85-20PU.pdf

Description:: IC MCU 8BIT 8KB FLASH 8DIP

In Stock:: 2530

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATTINY85-20PU Specifications

Package/Case:
8-DIP (0.300", 7.62mm)
Packaging:
Tube
Series:
AVR® ATtiny, Functional Safety (FuSa)
RoHS:
RoHS
Speed:
20MHz
RAM Size:
512 x 8
Core Size:
8-Bit
EEPROM Size:
512 x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
USI
Mounting Type:
Through Hole
Number of I/O:
6
Core Processor:
AVR
Data Converters:
A/D 4x10b
Oscillator Type:
Internal
Program Memory Size:
8KB (4K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

ATTINY85-20PU this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ATTINY85-20PU price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ATTINY85-20PU to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ATTINY85-20PU information

Views：

ATTINY85-20PU Typical application Circuitry

ATTINY85-20PU

The ATTINY85-20PU is a compact and versatile microcontroller from Atmel's AVR series, well-known for its small size and efficient performance, making it ideal for various embedded applications.

Core Characteristics

- Microcontroller Core: The ATTINY85-20PU operates on an 8-bit AVR processor, suitable for a wide range of control and computational tasks.

- Memory Specifications: Suitable for small to medium complexity programs, it has 512 bytes of SRAM, 512 bytes of EEPROM, and 8KB of flash memory.

- I/O Capabilities: The chip offers 6 general-purpose I/O pins, providing flexibility for interfacing with various peripherals.

Application Scenarios

The ATTINY85-20PU is often used in applications like wearable devices, simple automation systems, custom keyboards, hobbyist projects, and sensor interfacing.

Technical Parameters

- Voltage Range: Operates within a 2.7V to 5.5V range, adaptable to different power environments.

- Clock Speed: Capable of functioning at up to 20MHz, providing adequate processing speed for various tasks.

Example Application: Custom Keyboard Controller

Circuit Design:

1. Power Supply Connection: Join the ATTINY85-20PU's GND pin to the ground and its VCC pin to a 5V power source.

2. Key Switches Integration: Connect multiple key switches to the I/O pins (e.g., PB0 to PB5), allowing for individual key inputs.

3. USB Interface for Communication: Utilize the USI (Universal Serial Interface) pins, like PB2 (DO) and PB0 (DI), for USB communication.

4. Programming Interface: Program the ATTINY85-20PU using an ISP (In-System Programming) interface, connecting the SCK, MISO, MOSI, RESET, VCC, and GND pins to the corresponding pins on the microcontroller.

Design Considerations

- Power Source Compatibility: Ensure the power source aligns with the ATTINY85-20PU's voltage requirements.

- Key Switches Wiring: Confirm that all key switches are correctly wired and debounced, if necessary.

- USB Communication: Verify the USB communication setup for correct interfacing with a computer or other devices.

- Programming Accuracy: Check the ISP programming connections carefully to ensure successful firmware installation on the ATTINY85-20PU.

In conclusion, the ATTINY85-20PU is a highly effective microcontroller for small-scale, power-efficient projects that require a mix of digital I/O capabilities and simple interfacing. Its adaptability in various embedded system applications highlights its utility and popularity in the electronics realm.
