Microchip Technology ATTINY85-20MU

Part No.:: ATTINY85-20MU

Manufacturer:: Microchip Technology

Package:: 20-WFQFN Exposed Pad

Datasheet:: ATTINY85-20MU.pdf

Description:: IC MCU 8BIT 8KB FLASH 20QFN

In Stock:: 3688

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATTINY85-20MU Specifications

Package/Case:
20-WFQFN Exposed Pad
Packaging:
Tray
Series:
AVR® ATtiny, Functional Safety (FuSa)
RoHS:
RoHS
Speed:
20MHz
RAM Size:
512 x 8
Core Size:
8-Bit
EEPROM Size:
512 x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
USI
Mounting Type:
Surface Mount
Number of I/O:
6
Core Processor:
AVR
Data Converters:
A/D 4x10b
Oscillator Type:
Internal
Program Memory Size:
8KB (4K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

ATTINY85-20MU this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ATTINY85-20MU price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ATTINY85-20MU to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ATTINY85-20MU information

Views：

ATTINY85-20MU Typical application Circuitry

ATTINY85-20MU

The ATTINY85-20MU is a compact, high-performance microcontroller from the popular AVR Tiny series by Microchip (formerly Atmel), designed for simplicity and efficiency in embedded applications. This microcontroller is well-suited for a variety of projects, including wearables, sensor control, and light automation, due to its small footprint, low power consumption, and versatile feature set.

1. Power Supply Connections (VCC and GND): To power the ATTINY85-20MU, the VCC pin should be connected to a positive power supply, typically 2.7V to 5.5V, and the GND pin to the ground. It's crucial to ensure a stable power supply to maintain the microcontroller's reliable operation, and decoupling capacitors are recommended close to these pins to filter out noise.

2. Reset Pin (PB5/RESET): The RESET pin allows for resetting the microcontroller to its initial state. This pin can be left unconnected for applications not requiring external reset functionality; however, it's generally advisable to connect a pull-up resistor to VCC to prevent unintentional resets due to noise.

3. Digital I/O Pins: The ATTINY85-20MU features six general-purpose I/O pins (PB0 to PB4 and PB5/RESET if not used as RESET), which can be configured as either input or output. These pins support various functionalities, including digital input/output, PWM output, and analog input, providing flexibility in interfacing with sensors, actuators, and other peripherals.

4. Analog Input (ADC): Among the I/O pins, three (PB2, PB3, and PB4) double as analog input channels, enabling the ATTINY85-20MU to read analog signals. This feature is particularly useful for sensor interfacing in applications requiring environmental monitoring or user input via potentiometers.

5. Clock Source: The ATTINY85-20MU can utilize its internal oscillator as a clock source, eliminating the need for an external crystal or resonator for most applications. However, for applications requiring precise timing, an external clock source can be connected to the PB3 pin.

6. Programming Interface: The microcontroller can be programmed via the SPI interface using the PB0 (MOSI), PB1 (MISO), PB2 (SCK), and PB5 (RESET) pins. This interface is used to upload firmware to the ATTINY85-20MU, typically through an AVR ISP programmer or a similar device.

7. Power Saving Modes: The ATTINY85-20MU supports multiple power-saving modes, allowing for reduced power consumption in battery-operated applications. Proper utilization of these modes can significantly extend battery life in portable devices.

Incorporating the ATTINY85-20MU into a project requires careful attention to each pin's connection and functionality. By leveraging its versatile I/O options and efficient power management features, the ATTINY85-20MU can serve as the intelligent core of a wide range of embedded systems, offering both performance and flexibility in a compact package.
