Microchip Technology ATSAME70Q21B-CNT

Part No.:: ATSAME70Q21B-CNT

Manufacturer:: Microchip Technology

Package:: 144-LFBGA

Datasheet:: ATSAME70Q21B-CNT.pdf

Description:: IC MCU 32BIT 2MB FLASH 144LFBGA

In Stock:: 3248

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATSAME70Q21B-CNT Specifications

Package/Case:
144-LFBGA
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
SAM E70
RoHS:
RoHS
Speed:
300MHz
RAM Size:
384K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, MMC/SD/SDIO, SPI, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
114
Core Processor:
ARM® Cortex®-M7
Data Converters:
A/D 24x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
2MB (2M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
