Microchip Technology ATSAMD51N20A-AUT

Part No.:: ATSAMD51N20A-AUT

Manufacturer:: Microchip Technology

Package:: 100-TQFP

Datasheet:: ATSAMD51N20A-AUT.pdf

Description:: IC MCU 32BIT 1MB FLASH 100TQFP

In Stock:: 3632

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATSAMD51N20A-AUT Specifications

Package/Case:
100-TQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
SAM D51
RoHS:
RoHS
Speed:
120MHz
RAM Size:
256K x 8
Core Size:
32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, DMA, I²S, POR, PWM
Connectivity:
EBI/EMI, I²C, IrDA, LINbus, MMC/SD, QSPI, SPI, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
81
Core Processor:
ARM® Cortex®-M4F
Data Converters:
A/D 28x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
1MB (1M x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
