Microchip Technology ATMEGA8535L-8AU

Part No.:: ATMEGA8535L-8AU

Manufacturer:: Microchip Technology

Package:: 44-TQFP

Datasheet:: ATMEGA8535L-8AU.pdf

Description:: IC MCU 8BIT 8KB FLASH 44TQFP

In Stock:: 2896

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATMEGA8535L-8AU Specifications

Package/Case:
44-TQFP
Packaging:
Tray
Series:
AVR® ATmega
RoHS:
RoHS
Speed:
8MHz
RAM Size:
512 x 8
Core Size:
8-Bit
EEPROM Size:
512 x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
32
Core Processor:
AVR
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
8KB (4K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

ATMEGA8535L-8AU this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ATMEGA8535L-8AU price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ATMEGA8535L-8AU to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ATMEGA8535L-8AU information

Views：

ATmega8535L-8AU Typical application Circuitry

The ATmega8535L-8AU is a low-power CMOS 8-bit microcontroller from Microchip's AVR product line. It comes with 8KB of In-System Programmable Flash, along with numerous features including UARTs, SPI interface, and an 8-channel, 10-bit ADC. Here's a general description of an application circuit for this chip:

1. Power Supply: This microcontroller operates between 2.7-5.5 volts. Connect the VCC pin to the power source and use a decoupling capacitor between VCC and GND to filter out high-frequency noise. AVCC is the power supply for ADC converter and must not be left unconnected if the ADC functionality is in use.
2. Clock Source: The ATmega8535L-8AU has an internal calibrated oscillator but an external oscillator or crystal can be connected to XTAL1 and XTAL2 pins for higher precision.
3. Reset Circuit: The RESET pin can be connected to a push-button and a pull-up resistor to provide a manual reset. When the button is pressed, the RESET pin goes low and resets the microcontroller.
4. GPIO: This microcontroller provides various GPIO pins for interfacing with other components like LEDs, motors, sensors etc.
5. ADC Inputs: If your application requires analog inputs, connect your analog signals to the ADCx pins (where x is 0 to 7).
6. Programming Interface: The ATmega8535L-8AU supports In-System Programming (ISP) via the SPI pins (MOSI, MISO, SCK) and RESET pin.
You can use an AVR ISP programmer to upload your code. This is just a general idea of how an application circuit using the ATmega8535L-8AU might be constructed. Always refer to the datasheet and relevant application notes for detailed information and ensure that your specific requirements are met.
