Microchip Technology ATMEGA8535-16PU

Part No.:: ATMEGA8535-16PU

Manufacturer:: Microchip Technology

Package:: 40-DIP (0.600", 15.24mm)

Datasheet:: ATMEGA8535-16PU.pdf

Description:: IC MCU 8BIT 8KB FLASH 40DIP

In Stock:: 3651

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATMEGA8535-16PU Specifications

Package/Case:
40-DIP (0.600", 15.24mm)
Packaging:
Tube
Series:
AVR® ATmega
RoHS:
RoHS
Speed:
16MHz
RAM Size:
512 x 8
Core Size:
8-Bit
EEPROM Size:
512 x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Through Hole
Number of I/O:
32
Core Processor:
AVR
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
8KB (4K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

ATMEGA8535-16PU this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ATMEGA8535-16PU price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ATMEGA8535-16PU to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ATMEGA8535-16PU information

Views：

ATMEGA8535-16PU Typical application Circuitry

ATMEGA8535-16PU

The ATMEGA8535-16PU is a high-performance, low-power, 8-bit AVR RISC-based Atmel microcontroller that includes a 10-bit ADC, programmable watchdog timer with internal oscillator, serial programmable USART, 544B EEPROM, 512B SRAM, 32 general-purpose I/O lines, and flexible timer/counter with compare modes.

It is a product of Microchip and operates between 4.5V - 5.5V. Its impressive blend of capabilities makes it a suitable choice for a wide range of applications, including automation, sensor networks, and robotics.

To illustrate a specific circuit design application, we can consider the ATMEGA8535-16PU being used in a robotic control system:

1. Power Supply Pins: The VCC (Pin 10) and AVCC (Pin 30) pins should be connected to the power supply, and GND (Pins 11 & 31) should be tied to ground. It's important to place a decoupling capacitor between the power supply and ground pins to suppress high-frequency noise in the power supply lines.

2. Digital I/O Pins: The ATMEGA8535-16PU has 32 digital I/O pins (PORTA, PORTB, PORTC, PORTD). For instance, PORTB (Pins 1 to 8) can be used for interfacing with motors or servos of the robot.

3. Analog Input Pins: The microcontroller's ADC can be utilized to read values from sensors. For example, a distance sensor could be connected to ADC0 (Pin 40) to aid the robot in avoiding obstacles.

4. USART Pins: Data transmission could be handled via the USART interface using RXD (Pin 14) and TXD (Pin 15).

5. Programming the ATMEGA8535-16PU: The SPI interface is employed for programming the microcontroller, which includes SCK (Pin 17), MISO (Pin 18), and MOSI (Pin 19). Additionally, RESET (Pin 9) must be connected to your programmer.

When designing a circuit with the ATMEGA8535-16PU, it is essential to consider a few factors:

1. Supply Voltage: Ensure that the voltage applied to the VCC pin is within the specified operating range to avoid damaging the ATMEGA8535-16PU .

2. Sensor Compatibility: Sensors used should be compatible with the input voltage range of the ATMEGA8535-16PU is ADC.

3. Noise Filtering: Place a decoupling capacitor near the VCC and GND pins to minimize power supply noise.

4. Protection Mechanisms: Consider implementing protection measures, such as diodes, to safeguard against voltage spikes or electrostatic discharge.

5. Thermal Management: Pay attention to the thermal dissipation during your PCB layout design to prevent overheating, which could affect the performance of the ATMEGA8535-16PU .

In conclusion, the ATMEGA8535-16PU is a powerful, flexible, and robust microcontroller that lends itself to many applications. When designing circuits with it, it is critical to consider factors such as power supply voltage, sensor compatibility, noise filtering, protection mechanisms, and thermal management. For accurate and detailed information, always refer to the ATMEGA8535-16PU datasheet, which provides application-specific guidelines.
