Name: ATMEGA48PA-AU
Brand: Microchip Technology
SKU: ATMEGA48PA-AU
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology ATMEGA48PA-AU

Part No.:: ATMEGA48PA-AU

Manufacturer:: Microchip Technology

Package:: 32-TQFP

Datasheet:: ATMEGA48PA-AU.pdf

Description:: IC MCU 8BIT 4KB FLASH 32TQFP

In Stock:: 3033

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATMEGA48PA-AU Specifications

Package/Case:
32-TQFP
Packaging:
Tray
Series:
AVR® ATmega
RoHS:
RoHS
Speed:
20MHz
RAM Size:
512 x 8
Core Size:
8-Bit
EEPROM Size:
256 x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
23
Core Processor:
AVR
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
4KB (2K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

ATMEGA48PA-AU this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ATMEGA48PA-AU price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ATMEGA48PA-AU to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ATMEGA48PA-AU information

Views：

ATMEGA48PA-AU Typical application Circuitry

ATMEGA48PA-AU

ATMEGA48PA-AU is a low-power, 8-bit microcontroller from Atmel's AVR series, known for its efficiency and versatility. It is commonly used in applications that require a balance between power efficiency, processing capability, and I/O flexibility. Typical uses include embedded systems, IoT devices, battery-operated gadgets, and simple automation systems.

Application Scenario: Basic Home Automation Control System

An appropriate application for ATMEGA48PA-AU is in a basic home automation control system, designed to manage simple household tasks like lighting control and temperature monitoring.

Key Features of ATMEGA48PA-AU

- Optimal Processing Speed: Capable of operating at up to 20 MHz.

- Memory Specifications: Comes with 4 KB of Flash memory, 512 Bytes of SRAM, and 256 Bytes of EEPROM.

- I/O Flexibility: Offers 23 digital I/O pins and 6 analog input pins.

- Communication Protocols: Supports SPI, I2C, and UART.

Circuit Connection Details

1. Power Supply: Connect the VCC pin of ATMEGA48PA-AU to a 5V power source and the GND pin to the ground.

2. Light Control: Interface relay modules to digital I/O pins (e.g., PD0, PD1) to control lighting.

3. Temperature Sensor: Connect a digital temperature sensor (like the DS18B20) to a digital I/O pin (e.g., PD2) for ambient temperature measurement.

4. User Interface: Add buttons and a small LCD or LED display connected to the I2C/SPI pins for manual control and status display.

5. Programming Interface: Use the ISP (In-System Programming) interface for programming, involving MISO, MOSI, SCK, and RESET pins.

Programming Pins

- MISO (Master In Slave Out): For data reception during programming.

- MOSI (Master Out Slave In): For data transmission during programming.

- SCK (Serial Clock): Provides the clock for SPI communication during programming.

- RESET: To initiate the microcontroller's programming mode.

Design Considerations

- Stable Power Management: Ensure a consistent power supply for reliable operation.

- Sensor and Relay Integration: Accurately integrate the sensors and relays for effective control and monitoring.

- User Interface Clarity: Design the user interface to be simple and intuitive.

- Circuit Protection: Implement safeguards against over-voltage and electrical noise.

In conclusion, ATMEGA48PA-AU is highly suitable for developing a basic home automation control system, with attention to these detailed circuit design and connection guidelines.
