Microchip Technology ATMEGA48-20AUR

Part No.:: ATMEGA48-20AUR

Manufacturer:: Microchip Technology

Package:: 32-TQFP

Datasheet:: ATMEGA48-20AUR.pdf

Description:: IC MCU 8BIT 4KB FLASH 32TQFP

In Stock:: 3514

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATMEGA48-20AUR Specifications

Package/Case:
32-TQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
AVR® ATmega
RoHS:
RoHS
Speed:
20MHz
RAM Size:
512 x 8
Core Size:
8-Bit
EEPROM Size:
256 x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
23
Core Processor:
AVR
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
4KB (2K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

ATMEGA48-20AUR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ATMEGA48-20AUR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ATMEGA48-20AUR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ATMEGA48-20AUR information

Views：

ATMEGA48-20AUR Typical application Circuitry

An 8-bit microcontroller with great performance and low power consumption called the ATMEGA48-20AUR was created using the AVR enhanced RISC architecture. Due to its qualities, it can be applied to a number of different situations.

Typical Applications

- Battery-powered devices

- Sensing Systems

- Home automation

- DIY Electronics

- Data loggers

Notable Features

- Architecture: 8-bit AVR RISC

- Clock Speed: Max 20 MHz

- Flash Memory: 4 KB

- SRAM: 512 Bytes

- EEPROM: 256 Bytes

- GPIO Pins: 23

- Analog Inputs: 6-channel 10-bit ADC

- PWM Channels: 3

- I2C, SPI, UART: Yes

- Operating Voltage: 1.8 - 5.5V

Designing a Simple Temperature Data Logger

Necessary Components

- ATMEGA48-20AUR Microcontroller

- LM35 Temperature Sensor

- 16x2 LCD Display

- 10K Ohm Potentiometer

- Breadboard and Jump Wires

Circuit Connections

1. Power Connection

- VCC (Pin 7) and AVCC (Pin 20): Connect these to a stable voltage source, ranging from 1.8V to 5.5V.

- GND (Pins 8 and 22): Connect to circuit ground.

2. Temperature Sensor Interface

- Pin 23 (ADC0): Attach this pin to the output of LM35.

3. LCD Display

- Pin 12 (PB4) to Pin 19 (PB7): Connect these pins to the data pins (D4 to D7) of the LCD.

- Pin 28 (PC5): Connect to the RS pin on the LCD.

- Pin 27 (PC4): Connect to the Enable (E) pin on the LCD.

4. Potentiometer

- Pin 5 (PC2): Connect to the middle terminal of a 10K Ohm potentiometer for LCD contrast control.

Design Considerations

1. Voltage Consistency: The ATMEGA48-20AUR operates from 1.8V to 5.5V. The power supply needs to be consistent.

2. Sensor Accuracy: For precise temperature readings, proper placement and orientation of the LM35 sensor are crucial.

3. LCD Power Requirements: Ensure the LCD and ATMEGA48-20AUR are compatible in terms of voltage and current ratings.

4. Programming Space: Given the limited 4 KB of Flash memory in the ATMEGA48-20AUR, code should be optimized for space.

5. Protection: Consider including overvoltage and reverse polarity protection in your design.

In summary, the ATMEGA48-20AUR offers a versatile set of features that make it well-suited for applications like temperature data logging. However, when designing circuits with this chip, factors like voltage stability, sensor placement, and code efficiency are critical considerations.
