Microchip Technology ATMEGA48-20AU

Part No.:: ATMEGA48-20AU

Manufacturer:: Microchip Technology

Package:: 32-TQFP

Datasheet:: ATMEGA48-20AU.pdf

Description:: IC MCU 8BIT 4KB FLASH 32TQFP

In Stock:: 3550

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATMEGA48-20AU Specifications

Package/Case:
32-TQFP
Packaging:
Tray
Series:
AVR® ATmega
RoHS:
RoHS
Speed:
20MHz
RAM Size:
512 x 8
Core Size:
8-Bit
EEPROM Size:
256 x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
23
Core Processor:
AVR
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
4KB (2K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

ATMEGA48-20AU this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ATMEGA48-20AU price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ATMEGA48-20AU to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ATMEGA48-20AU information

Views：

ATmega48-20AU Typical application Circuitry

A low-power, 8-bit CMOS microcontroller from Microchip's AVR family is the ATmega48-20AU. The device is equipped with 4KB ISP Flash memory, 512 Byte SRAM, and a 6 or 8 channel 10-bit A/D converter. An explanation of a typical application circuit is provided below:

1. Power Supply: The ATmega48-20AU operates in the voltage range of 2.7 - 5.5V. The VCC pins and AVCC (analog power supply) pins should be connected to a clean and stable power source. Near these pins, decoupling capacitors are frequently employed to block high-frequency noise.
2. Clock Source: The ATmega48-20AU can utilize an internal calibrated oscillator. However, for greater precision, an external crystal oscillator can be used. The external oscillator, typically between 8 MHz to 20 MHz, should be connected to the XTAL1 and XTAL2 pins.
3. Reset Mechanism: It's important to have a reset circuit for proper operation. To avoid accidental resets, a pull-up resistor and a push-button switch can be attached to the RESET pin.
4. GPIO: The ATmega48-20AU has numerous General Purpose Input/Output (GPIO) pins that can be interfaced with a wide range of peripherals, such as sensors, LEDs, switches, and so on.
5. ADC Inputs: If your application requires analog-to-digital conversion, you can utilize the microcontroller's ADC inputs (ADC0 - ADC5 or ADC7).
6. Programming Interface: The ATmega48-20AU can be programmed using In-System Programming (ISP), which involves connections to the SPI (MOSI, MISO, SCK) pins and the RESET pin.
This is a general description of an application circuit for the ATmega48-20AU microcontroller. Depending on your particular application, the specifics will vary. Always refer to the ATmega48-20AU datasheet and application notes for detailed guidelines.
