Name: ATMEGA325-16AU
Brand: Microchip Technology
SKU: ATMEGA325-16AU
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology ATMEGA325-16AU

Part No.:: ATMEGA325-16AU

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: ATMEGA325-16AU.pdf

Description:: IC MCU 8BIT 32KB FLASH 64TQFP

In Stock:: 2981

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATMEGA325-16AU Specifications

Package/Case:
64-TQFP
Packaging:
Tray
Series:
AVR® ATmega
RoHS:
RoHS
Speed:
16MHz
RAM Size:
2K x 8
Core Size:
8-Bit
EEPROM Size:
1K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
SPI, UART/USART, USI
Mounting Type:
Surface Mount
Number of I/O:
54
Core Processor:
AVR
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
32KB (16K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
