Microchip Technology ATMEGA2561-16AUR

Part No.:: ATMEGA2561-16AUR

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: ATMEGA2561-16AUR.pdf

Description:: IC MCU 8BIT 256KB FLASH 64TQFP

In Stock:: 3896

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATMEGA2561-16AUR Specifications

Package/Case:
64-TQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
AVR® ATmega
RoHS:
RoHS
Speed:
16MHz
RAM Size:
8K x 8
Core Size:
8-Bit
EEPROM Size:
4K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
EBI/EMI, I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
54
Core Processor:
AVR
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
256KB (128K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

ATMEGA2561-16AUR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ATMEGA2561-16AUR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ATMEGA2561-16AUR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ATMEGA2561-16AUR information

Views：

ATMEGA2561-16AUR Typical application Circuitry

An 8-bit microcontroller built on the AVR improved RISC architecture is called the ATMEGA2561-16AUR. This chip provides a robust platform for embedded system development, courtesy of its rich set of peripherals and expansive memory resources. Created by Microchip Technology, it offers 256 KB of Flash memory, 8 KB of SRAM, and a plethora of connectivity options including USART, SPI, and TWI (I2C).

Applications Scenarios

- Robotics

- Automotive Systems

- Medical Devices

- Data Logging and Monitoring

- Automation Controls

Key Features

- Architecture: 8-bit AVR

- Clock Speed: Up to 16 MHz

- Flash Memory: 256 KB

- SRAM: 8 KB

- I/O Pins: 54

- Operating Voltage: 4.5V to 5.5V

Application Scenario: Data Logging System

Components Required:

- ATMEGA2561-16AUR microcontroller

- SD Card Module

- Real Time Clock (RTC) Module (DS3231)

- LEDs (Status Indicators)

- 16 MHz Crystal Oscillator

- Two 22pF Capacitors

- Pull-up and Pull-down resistors

Detailed Circuit Connection:

1. Power Configuration

- VCC (Pins 10, 30, 50): Link these to a stable 5V power supply.

- GND (Pins 11, 31, 51): Connect these to the circuit's ground plane.

2. Crystal Oscillator Placement

- XTAL1 (Pin 12) and XTAL2 (Pin 13): Add a 16MHz crystal oscillator here and attach 22pF capacitors from each pin to the ground.

3. RTC Module Integration

- PC0 (Pin 22) and PC1 (Pin 23): Connect these pins to the SDA and SCL lines of the DS3231 RTC module. Utilize pull-up resistors on both lines.

4. SD Card Connectivity

- PB0 (Pin 1), PB1 (Pin 2), PB2 (Pin 3): These pins control the SPI connection for the SD card. PB0 for SCK, PB1 for MISO, and PB2 for MOSI.

5. Status LEDs

- PD0 to PD2 (Pins 14 to 16): Attach LEDs through 330-ohm resistors for status indicators (Read/Write/Error).

Considerations During Design:

1. Power Reliability: ATMEGA2561-16AUR demands a stable power source; any voltage fluctuation can lead to erroneous behavior.

2. Signal Integrity: Ensure that the traces for high-speed signals like SPI are short and matched in impedance.

3. Code Efficiency: Given the 256 KB Flash of ATMEGA2561-16AUR, efficient code is less of a concern but still important for optimal performance.

4. Timing Accuracy: Ensure that the RTC module is precisely calibrated, as inaccurate timekeeping will defeat the purpose of a data logging system.

5. Thermal Management: Though not very likely with low-power microcontrollers like ATMEGA2561-16AUR, always check the thermal characteristics in a tightly enclosed setup.

The ATMEGA2561-16AUR serves as a highly adaptable microcontroller unit, providing developers the freedom to implement complex embedded systems. Attention to design intricacies is essential for leveraging its extensive capabilities fully.
