Name: ATMEGA16U2-AUR
Brand: Microchip Technology
SKU: ATMEGA16U2-AUR
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology ATMEGA16U2-AUR

Part No.:: ATMEGA16U2-AUR

Manufacturer:: Microchip Technology

Package:: 32-TQFP

Datasheet:: ATMEGA16U2-AUR.pdf

Description:: IC MCU 8BIT 16KB FLASH 32TQFP

In Stock:: 3679

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATMEGA16U2-AUR Specifications

Package/Case:
32-TQFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
AVR® ATmega
RoHS:
RoHS
Speed:
16MHz
RAM Size:
512 x 8
Core Size:
8-Bit
EEPROM Size:
512 x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
SPI, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
22
Core Processor:
AVR
Data Converters:
-
Oscillator Type:
Internal
Program Memory Size:
16KB (8K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C

ATMEGA16U2-AUR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ATMEGA16U2-AUR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ATMEGA16U2-AUR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ATMEGA16U2-AUR information

Views：

ATMEGA16U2-AUR Typical application Circuitry

ATMEGA16U2-AUR

The ATMEGA16U2-AUR is an 8-bit microcontroller from the AVR family developed by Microchip Technology. This microcontroller features USB connectivity, making it an ideal choice for applications requiring interfacing with computers or other USB devices. The ATMEGA16U2-AUR is particularly noted for its ease of integration into USB-based projects due to its in-built USB module, offering a streamlined approach for developers working on USB communication interfaces.

Application Scenarios

The ATMEGA16U2-AUR is extensively used in applications such as USB peripheral development, custom USB devices, embedded systems requiring USB connectivity for programming or communication, and as a USB-to-serial converter in development boards. Its USB functionality enables it to act as an interface between a computer and other hardware, facilitating data transfer and device control.

Parameter Features

- Core: 8-bit AVR processor, ensuring efficient operation and compatibility with the AVR instruction set.

- Memory: 16KB of flash memory, 512 Bytes of EEPROM, and 1KB of SRAM, providing ample space for code and data storage.

- USB Interface: Integrated USB 2.0 Full-speed/low-speed device module for direct USB communication.

- I/O Pins: Offers up to 22 programmable I/O lines for versatile hardware interfacing.

Circuit Design: USB-to-Serial Converter

Application Scenario: Utilizing the ATMEGA16U2-AUR to create a USB-to-serial converter, which can be used to add a USB communication interface to devices with a UART port, such as microcontrollers or GPS modules without native USB support.

Power Supply Connection

- VCC and GND: Connect to a stable 5V power source. The power supply must be regulated to ensure the ATMEGA16U2-AUR operates within its specified power requirements.

USB Interface

- D+ and D- Pins: Connect to the USB connector's D+ and D- lines. These pins are critical for USB communication and must be accurately connected for the device to communicate over USB.

Programming Interface

- MOSI, MISO, SCK, RESET: These pins are used for loading firmware onto the ATMEGA16U2-AUR. An ISP (In-System Programmer) is connected to these pins for programming the microcontroller with the USB-to-serial conversion firmware.

Serial Communication

- RXD and TXD Pins: Connect these UART pins to the UART TX and RX pins of the device you wish to communicate with. This connection enables serial data to be transferred between the ATMEGA16U2-AUR and the connected device.

Considerations

When designing a circuit with the ATMEGA16U2-AUR, several considerations are paramount. Power integrity must be ensured with proper decoupling capacitors near the VCC and GND pins to prevent noise on the power supply line. The USB signal integrity is also critical; impedance matching and minimal path length for D+ and D- lines can help maintain signal quality. Additionally, firmware development for the ATMEGA16U2-AUR must comply with USB specifications to ensure seamless communication.

In summary, the ATMEGA16U2-AUR's integration into a USB-to-serial converter circuit highlights its capability to bridge traditional serial communication devices with modern USB interfaces. This application underscores the versatility and utility of the ATMEGA16U2-AUR in developing USB-based devices and systems, emphasizing the importance of careful circuit design to optimize performance and reliability.
