Name: ATMEGA128L-8AN
Brand: Microchip Technology
SKU: ATMEGA128L-8AN
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology ATMEGA128L-8AN

Part No.:: ATMEGA128L-8AN

Manufacturer:: Microchip Technology

Package:: 64-TQFP

Datasheet:: ATMEGA128L-8AN.pdf

Description:: IC MCU 8BIT 128KB FLASH 64TQFP

In Stock:: 2064

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATMEGA128L-8AN Specifications

Package/Case:
64-TQFP
Packaging:
Tray
Series:
AVR® ATmega
RoHS:
RoHS
Speed:
8MHz
RAM Size:
4K x 8
Core Size:
8-Bit
EEPROM Size:
4K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
EBI/EMI, I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
53
Core Processor:
AVR
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
128KB (64K x 16)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 105°C (TA)
